Stainless Steel Monoflange Valves

Stainless Steel Monoflange Valves :

BONNET ASSLY. FEATURES :
Design
Screwed bonnet
Bonnet
Back seat blowout proof
Stem
Rolled stem operating threads.
Stem tip
Self centering non rotating, rotating, regulatingand soft seated
Bonnet Pusher
Silver plated for anti galling freezing for increased stem cycle life
Dust Cap
Protects stem threads from ingrease of contamination. Colour coded identification.
Handle
Low torque operating
Sealing
Leak tight seal for easy operation of valve.

SPECIFICATIONS :
Size		1/4", 3/8", 1/2"
End ports		NPT, BSPT, socket weld
Process flange size		1/2",3/4",1",1-1/2", 2"
Flange pressure rating		150#, 300#, 600#, 900#, 1500#, 2500#
Flange end		Raise Face. Ring Joint
Bleed port		1/4", 3/8", 1/2"
Version		Straight & angle
Max. Std. Pressure		6000 Psi (413 Bar)
Temperature Rating		PTFE 450° F (232° C) Grafoil 700° F (371° C)
Material		SS 316, SS 304, C.S., F11, Hastelloy, Monel
Standard seat		Ø4mm
Panel mount option		All valves are 100% Factory tested prior to shipment.
